Vibrating screen VS Big
ASCO® VS COMPACT – Compact screening plant with high performance and modular flexibility
Machine highlights
- High screening performance
- Flexible and modular
- Adjustable screening technology
- Versatile screen coverings
- Separation into 3 fractions
- Modular extension with conveyor belts
- Easily replaceable sieve pads
Frequently Asked Questions
What advantages does the VS Big offer compared to smaller screening plants?
The VS Big is designed for heavy loads and larger material volumes. It boasts a robust construction, fast screen media changes, a large screening area, and high efficiency – ideal for professional applications with large material volumes.
Is the VS Big’s equipment modularly adaptable – depending on customer requirements?
Yes, the VS Big has a modular design. It can be individually configured – with or without a hopper, divider (only for two-deck models), support legs, or poles – just like the smaller models (VS Medi and VS Compact). This makes it perfectly adaptable to different applications and requirements.
How big and how heavy is the VS Big Two-deck?
The system measures 2,41 m long, 3,62 m wide, and 2,85 m high. This makes it compact enough for mobile use, yet powerful enough for large volumes of material. It weighs 2.457 kg. The robust construction ensures stability during operation without compromising transportability.
Is there an opportunity to see or test a machine in action before purchasing it?
Yes, we offer demonstrations at our premises or at existing customers' locations. Alternatively, we are happy to send video footage or arrange an on-site appointment with a sales partner.
Submit a product inquiry now:
VS BIG
ASCO ® SCREEN
Description
Specifications
Components
Modularity
Videos
Description
Robust. Powerful. Versatile. - The ASCO VS BIG is the heavyweight among ASCO Technology's vibrating screens and was specially developed for demanding screening applications with high throughput. With a generous screening area of 12,8m², two powerful vibration motors and a sturdy steel frame, this model meets all requirements in construction, agriculture, gardening and landscaping as well as in the recycling sector.
For large quantities in a short time
The System capacity of up to 130 m³ per hour do that ASCO VS BIG The ideal choice for companies that need to process large quantities of material quickly and efficiently. Even the most diverse materials – from construction rubble and compost to soil and sand – can be separated reliably. Thanks to the maximum bucket width of 3 mThe screen is ideal for direct feeding by wheel loaders or excavators.
Versatile and ready to use
The ASCO VS BIG vibrating screen is more than just large—it's also well thought out. Thanks to its sturdy construction, ease of use, and universal applicability, it offers a durable and economical solution for anyone who values quality and productivity.
ASCO VS BIG – If you are looking for screening performance without compromise
Whether on the construction site, in the composting plant or on the farm – with the ASCO VS BIG Rely on a vibrating screen that operates reliably even under heavy loads. Efficiency, robustness, and ease of use make this model the first choice for professional users.
Specifications
| Property | Value |
|---|---|
| system performance | 40–130 m³/h |
| Maximum bucket width | 3 m |
| Screen area | 12,8m² |
| Horsepower | 400 V / 2 × 1,5 kW |
| Weight | 2457 kg |
| Width | 3,62 m |
| Length | 2,41 m |
| Height | 2,85 m |
| loading height | 2,46 m |
Components
FUNNEL
Weight: 16 kgIncreases the efficiency of material feeding.
Bar Sizer
Weight: 130 kgAdditional separation option for coarse material with improved screening results leads to a fine fraction.
SUPPORT FEET
Weight (4 pieces): 64 kgQuickly adjust the screen angle and compensate for uneven terrain when setting up the machine.
Modularity
SINGLE-DECK SCREEN
DOUBLE-DECK SCREEN
Videos
